- Brand
- Waircom
- Family
- FM100
- Switch Model
- Reed switch
- Contacts / Output
- N.O.
- Number of Wires
- 3-wire
- Termination
- M8 ring-nut connector
ParameterValue
- Operating Voltage
- 3 ÷ 30 V AC/DC
- Max Exchange Current
- 200 mA
- Max Power
- 6 W
- Operating Frequency
- 500 Hz
- Working Temperature
- -10 ÷ +70 °C
- Protection Class
- IP 67
ParameterValue
