77.55.8.230.8250 - Finder Solid-State Relay, 50000 mA 280 VAC (Heatsink)

77.55.8.230.8250 - Finder Solid-State Relay, 50000 mA 280 VAC (Heatsink)

SKU77.55.8.230.8250BrandFinder
AED 194.00
AED 194.00
Sale Sold out
Shipping calculated at checkout.

The 77.55.8.230.8250 is a dependable solid state relay from Finder, part of the 77 series. Rated for a maximum load of 50000 mA at 280 VAC with Zero-Cross switching, controlled by 230 VAC to 230 VAC input. This Heatsink relay uses Zero-Cross output, providing millions of silent, maintenance-free switching cycles for heaters, motors, and process control loads.

View full details
ParameterValue
Brand
Finder
Maximum Load Current
50000 mA
Mounting Type
Heatsink
Maximum Load Voltage
280 VAC
Minimum Load Voltage
21.6 VAC
Maximum Control Voltage
230 VAC
Switching Type
Zero-Cross
Control Voltage Range
90280 VAC
Minimum Load Current
250 mA
Terminal Type
Screw
Contact Configuration
SPST
ParameterValue
Package Style
Hockey Puck
Series
77
Load Voltage Range
21.6–280 VAC
Maximum Turn On Time
40 ms
Dimensions
44.5 x 36.4 x 57.7 mm
Depth
44.5 mm
Operating Temperature Range
-30–80 °C
Height
36.4 mm
Off State Leakage Current
10 mA
Length
57.7 mm
