• Finder - 50.12.9.005.1000
1 1

Finder Force Guided Relays 50.12.9.005.1000

Finder Force Guided Relays 50.12.9.005.1000

SKU50.12.9.005.1000BrandFinder
AED 50.97
AED 50.97
Sale Sold out
Shipping calculated at checkout.

Finder, Relay guided contacts Finder 50, 5V dc, 2 poles, DPDT, 8A, Printed circuit board mounting

View full details
ParameterValue
Brand
Finder
Coil Voltage
5V dc
Mounting Type
PCB Mount
Contact Configuration
DPDT
Number of Poles
2
Coil Resistance
35?
Switching Current
8A
Coil Power
700mW
Maximum Switching Voltage AC
400V
Maximum Switching Voltage (AC)
400V
Terminal Type
Through Hole
Standards Met
EN61810-3 type B
ParameterValue
Series
50
Depth
12.4mm
Height
25mm
Minimum Operating Temperature
-40°C
Maximum Operating Temperature
+70°C
Isolation Coil To Contact
6kV
Life
100000 (Electrical) Cycles, 10000000 (Mechanical)Cycles
Maximum Switching Power AC
2 kVA
Length
29mm
Contact Material
Silver Alloy
Country of Origin
Spain
