41.52.9.048.0010 - Finder DPDT Power Relay, 8000 mA (48 VDC)

41.52.9.048.0010 - Finder DPDT Power Relay, 8000 mA (48 VDC)

SKU41.52.9.048.0010BrandFinder
AED 21.00
AED 21.00
Sale Sold out
Shipping calculated at checkout.

The 41.52.9.048.0010 is a precision-engineered power relay from Finder, part of the 41 Series. Featuring a DPDT contact configuration rated at 8000 mA switching current, operating on a 48 VDC coil. Its Silver Alloy contacts minimize resistance and arcing, with PCB-Mount installation and Through-Hole terminals, designed for reliable load switching of motors, heaters, and lighting in industrial control panels.

View full details
ParameterValue
Brand
Finder
Application
Power
Coil Power
400 mW
Coil Resistance
5760 Ω
Coil Voltage
48 VDC
Contact Configuration
DPDT
Contact Material
Silver Alloy
Depth
12.5 mm
Height
15.7 mm
Latching
No
ParameterValue
Length
29 mm
Maximum Operating Temperature
85 °C
Maximum Switching Power AC
2 kVA
Minimum Operating Temperature
-40 °C
Mounting Type
PCB-Mount
Number of Poles
2
Series
41 Series
Switching Current
8000 mA
Terminal Type
Through-Hole
