Takamisawa Signal Relays RY-24W-K

Takamisawa Signal Relays RY-24W-K

SKURY-24W-KBrandTakamisawa
AED 8.65
AED 8.65
Sale Sold out
Shipping calculated at checkout.

Takamisawa, RY-24W-K PCB relay 24 V/DC 1 A 2 switches 1 pc.

View full details

Buying for a project?

Custom pricing on bulk orders & project quotes

Our specialists confirm compatibility, check stock across our brand network, and respond with a formal quote within one business day.

Talk to a Specialist
  • Brand: Fujitsu
  • Coil Voltage: 24V dc
  • Contact Configuration: DPDT
  • Mounting Type: Through Hole
  • Maximum Switching Current AC: 1 A
  • Maximum Switching Current (AC): 1 A
  • Maximum Switching Current DC: 1 A
  • Maximum Switching Current (DC): 1 A
  • Maximum Switching Voltage AC: 120V ac
  • Maximum Switching Voltage (AC): 120V ac
  • Maximum Switching Voltage DC: 60V dc
  • Maximum Switching Voltage (DC): 60V dc
  • Series: RY
  • Maximum Switching Power DC: 24 W
  • Maximum Switching Power (DC): 24 W
  • Length: 20.2mm
  • Latching: No
  • Depth: 9.8mm
  • Height: 12.5mm
  • Terminal Type: Through Hole
  • Application: Signal
  • Switching Current: 1A
  • Number of Poles: 2
  • Minimum Operating Temperature: -30°C
  • Coil Power: 200mW
  • Maximum Operating Temperature: +90°C
  • Isolation Coil To Contact: 1kV ac
  • Maximum Switching Power AC: 60VA
  • Coil Resistance: 2880?
  • Contact Material: Gold Plated
  • Country of Origin: Japan
