IFM OGS381 - Through-Beam Sensor Transmitter, Infrared, < 15 m range, Stainless steel, IP 69K

Q: What is the IFM OGS381?

The IFM OGS381 is the transmitter unit of an infrared through-beam sensor system that emits an 860 nm infrared beam to a separate receiver.

Q: What is the range of the IFM OGS381?

The IFM OGS381 has an operating range of less than 15 m to its associated receiver.

Q: What light type does the IFM OGS381 use?

The IFM OGS381 uses infrared light with a wavelength of 860 nm.

Q: What is the operating voltage of the IFM OGS381?

The IFM OGS381 operates on 10...30 V DC and draws 17 mA.

Q: What protection rating does the IFM OGS381 have?

The IFM OGS381 has a stainless steel housing rated IP 65, IP 67, IP 68 and IP 69K.

Q: What is the electrical connection of the IFM OGS381?

The IFM OGS381 connects via one M12 A-coded connector with 4 pins.

Q: What is the operating temperature of the IFM OGS381?

The IFM OGS381 operates in an ambient temperature range of -25 to 80 °C.

SKUOGS381BrandIFM

AED 483.00

Sale Sold out

Shipping calculated at checkout.

Quantity

IFM OGS381 Through-Beam Sensor Transmitter — Hygienic stainless steel infrared transmitter for through-beam detection up to 15 m. Infrared 860 nm, range < 15 m, 10...30 V DC, 17 mA, M12, stainless steel, IP 65/67/68/69K.

Shipping & Returns

Same-day dispatch across UAE

Order before 2 PM (Sun–Thu). Next-day delivery to Dubai, Sharjah, Abu Dhabi. 2–4 days to other emirates.

7-day return window

Sealed, unused items can be returned within 7 days for full refund or replacement.

Compatibility-checked

Our specialists review every bulk quote to ensure the part fits your application before you commit.

MPN / SKU: OGS381

Also known as: IFM OGS381 photoelectric sensor / through-beam sensor / light barrier.

OGS381 Applications

The OGS381 is the transmitter unit of an infrared through-beam sensor system designed for the food and beverage industry. It emits an 860 nm infrared beam reaching an associated receiver over distances up to 15 m for reliable detection of objects, even transparent or dark ones. The rugged stainless steel housing with protection ratings up to IP 69K withstands high-pressure washdown and hygienic cleaning, while a green LED indicates operation. The compact rectangular housing with M18 thread simplifies mounting in tight production lines.

OGS381 Specifications

Brand	IFM	Product Type	Through-beam sensor transmitter with infrared light for reliable object detection in the food and beverage industry.
IFM Type Code	OGSIOOKG/IO-LINK/US/V4A/CUBE	Function	Transmitter
Light type	Infrared light	Wavelength	860 nm
Range	< 15 m	Max. light spot diameter	200 mm
Operating voltage	10...30 V DC	Current consumption	17 mA
Electrical connection	1 x M12, A-coded, 4 pins	Housing material	Stainless steel (630/1.4542/17-4 PH); rear: PEI
Protection rating	IP 65; IP 67; IP 68; IP 69K	Ambient temperature	-25...80 °C
Dimensions	52.9 x 20 x 34.6 mm	Weight	78.35 g
Indication	1 x LED, green
