IFM SL5101 - Airflow Monitor, Relay Output, 24 V DC

IFM SL5101 - Airflow Monitor, Relay Output, 24 V DC

SKUSL5101BrandIFM
AED 450.00
AED 450.00
Sale Sold out
Shipping calculated at checkout.

50 in stock

IFM SL5101 Airflow Monitor — 18...30 V DC supply with potential-free relay output, PUR cable and UL approval. airflow monitoring for ventilation and building automation, Ø 23 mm clamp fitting, 18...30 V DC, potential-free relay output 3 A, potentiometer switch-point setting, titanium sensor tip, IP65, UL approved.

Shipping & Returns

Same-day dispatch across UAE

Order before 2 PM (Sun–Thu). Next-day delivery to Dubai, Sharjah, Abu Dhabi. 2–4 days to other emirates.

7-day return window

Sealed, unused items can be returned within 7 days for full refund or replacement.

Compatibility-checked

Our specialists review every bulk quote to ensure the part fits your application before you commit.

MPN / SKU: SL5101

Also known as: IFM SL5101 flow sensor / flow switch / flow meter / flow monitor.

SL5101 Applications

The IFM SL5101 airflow monitor confirms air movement in ventilation ducts and building-automation systems running on 24 V DC control power. It protects fans, heaters and filters by signalling loss of airflow through a potential-free relay contact. Mounted via a Ø 23 mm clamp fitting with potentiometer switch-point setting, and UL approved, it fits neatly into HVAC and machine control panels.

SL5101 Specifications

Brand IFM Product Type Airflow monitor
Product type code SLG23CEEAKOG/24VDC Media Gases (air)
Medium temperature -10...50 °C Process connection Clamp fitting Ø 23 mm
Operating voltage 18...30 V DC Current consumption 50 mA
Output 1 relay, 3 A (30 V DC / 250 V AC) Setting range 100...1000 cm/s
Switch-point setting Potentiometer Protection IP 65
Approval cULus Weight 192.5 g
Electrical connection 2 m PUR cable, 4 x 0.5 mm²

SL5101 Datasheet & Manual

Download Datasheet & ManualIFM SL5101 · PDF · Official IFM document

SL5101 – Frequently Asked Questions (FAQ)

What is the setting range of the IFM SL5101 airflow monitor?

The IFM SL5101 has a setting range of 100...1000 cm/s, with greatest sensitivity in the 100...400 cm/s range.

What output does the IFM SL5101 provide?

The IFM SL5101 has one relay output rated 3 A (30 V DC / 250 V AC; cULus: 30 V DC / AC); the relay is energised when flow is present.

What is the operating voltage and current consumption of the IFM SL5101?

The IFM SL5101 operates on 18...30 V DC and draws 50 mA.

What is the response time of the IFM SL5101?

The IFM SL5101 has a response time of 3...60 s and a 60 s power-on delay time.

What is the IP rating and temperature range of the IFM SL5101?

The IFM SL5101 is rated IP 65, with an ambient and medium temperature range of -10...50 degrees C.

What materials are used in the IFM SL5101 and its process connection?

The IFM SL5101 has a PBT housing with a titanium sensor surface and mounts via a clamp adapter of diameter 23 mm.

What electrical connection does the IFM SL5101 use?

The IFM SL5101 is supplied with a 2 m PUR cable, 4 x 0.5 mm2, PVC.

Does the IFM SL5101 have status indication?

Yes, the IFM SL5101 includes red and green LED indicators for status display.
