Finder Power Relays 34.51.7.012.0019

Finder Power Relays 34.51.7.012.0019

AED 20.07

AED 20.07

Sale Sold out

Shipping calculated at checkout.

Finder, 34 Series Power Rel, SPDT, 12V dc coil, Printed circuit board mount

Quantity

View full details

Specifications

Brand: Finder
Coil Voltage: 12V dc
Contact Configuration: SPDT
Mounting Type: PCB Mount
Switching Current: 6A
Number of Poles: 1
Latching: No
Terminal Type: Through Hole
Maximum Switching Voltage AC: 400V ac
Length: 28mm
Coil Resistance: 840?

Coil Power: 170mW
Series: 34 Series
Minimum Operating Temperature: -40°C
Maximum Operating Temperature: +85°C
Isolation Coil To Contact: 6kV
Depth: 5mm
Life: 10000000 (DC Mechanical) cycles, 60000 (Electrical) cycles
Height: 15mm
Contact Material: Silver Alloy
Maximum Switching Power AC: 1.5 kVA
