3RP2505-1BB30 - Siemens Multifunction Timer Relay, 0.05 s – 100h 24 V AC/DC (DIN Rail)

3RP2505-1BB30 - Siemens Multifunction Timer Relay, 0.05 s – 100h 24 V AC/DC (DIN Rail)

SKU3RP2505-1BB30BrandSiemens
AED 258.00
AED 258.00
Sale Sold out
Shipping calculated at checkout.

The 3RP2505-1BB30 is a versatile timer relay manufactured by Siemens, part of the 3RP25 series. Featuring Multifunction timing mode with a configurable time range of 0.05 s – 100h across Hours, Minutes, Seconds increments, this timer relay operates on a 24 V AC/DC supply voltage. It provides DPDT output contacts rated for 3 A at 24 V AC/DC, with Screw termination and DIN Rail installation. With multi function timer, a External power supply configuration, it delivers precise, repeatable time control for industrial automation sequences, motor starting, lighting control, HVAC scheduling, and process timing applications.

View full details
ParameterValue
Supply Voltage
24 V AC/DC
Mounting Type
DIN-Rail
Mode of Operation
Multifunction
Time Range
0.05 s to 100 h
Number of Contacts
2
Number of Timer Functions
Multi-Function
Contact Configuration
DPDT
Time Increment
hours, minutes, seconds
Maximum Current
3 A
Maximum Voltage
24 V AC/DC
Terminal Type
Screw
ParameterValue
Switch Configuration
DP4T
Width
91.6 mm
Power Supply
External
Minimum Current
10 mA
Series
3RP25
Depth
100 mm
Maximum Operating Temperature
60 °C
Length
22.5 mm
Minimum Operating Temperature
-25 °C
Contact Material
Silver-Tin-Oxide

More in Relays

View all 785
3RP2005-1AP30 - Siemens Multifunction Timer Relay, 0.05 – 100 h, 0.05 – 100 min, 0.05 – 100s 110 – 240 V AC, 24 V AC/DC (DIN Rail) Siemens3RP2005-1AP303RP2005-1AP30 - Siemens Multifunction Timer Relay, 0.05 – 100 h, 0.05 – 100 min, 0.05 – 100s 110 – 240 V AC, 24 V AC/DC (DIN Rail) AED 577.00 excl. vat 3RP2005-1AQ30 - Siemens Multifunction Timer Relay, 0.05 – 100 h, 0.05 – 100 min, 0.05 – 100s 100 – 127 V AC, 24 V AC/DC (DIN Rail) Siemens3RP2005-1AQ303RP2005-1AQ30 - Siemens Multifunction Timer Relay, 0.05 – 100 h, 0.05 – 100 min, 0.05 – 100s 100 – 127 V AC, 24 V AC/DC (DIN Rail) AED 260.00 excl. vat Weidmuller Safety Relays 1319280000 Weidmuller1319280000Weidmuller Safety Relays 1319280000 AED 1,030.21 excl. vat LH1546AEFTR - Vishay Solid-State Relay, 120 mA 350 VAC/DC (Surface-Mount) VishayLH1546AEFTRLH1546AEFTR - Vishay Solid-State Relay, 120 mA 350 VAC/DC (Surface-Mount) AED 3.79 excl. vat LH1540AABTR - Vishay Solid-State Relay, 250 mA 350 V (PCB-Mount) VishayLH1540AABTRLH1540AABTR - Vishay Solid-State Relay, 250 mA 350 V (PCB-Mount) AED 17.00 excl. vat Te-connectivity Signal Relays IM16GR Te-connectivityIM16GRTe-connectivity Signal Relays IM16GR AED 8.61 excl. vat Te-connectivity Signal Relays IM02GR Te-connectivityIM02GRTe-connectivity Signal Relays IM02GR AED 14.13 excl. vat V23092A1048A301 - Te-connectivity SPDT Power Relay, 6000 mA (48 VDC) Te-connectivityV23092A1048A301V23092A1048A301 - Te-connectivity SPDT Power Relay, 6000 mA (48 VDC) AED 45.00 excl. vat
