IFM SM6020 - Magnetic-Inductive Flow Meter, 0.05...35 l/min, G 1/2, IO-Link

IFM SM6020 - Magnetic-Inductive Flow Meter, 0.05...35 l/min, G 1/2, IO-Link

SKUSM6020BrandIFM
AED 2,212.00
AED 2,212.00
Sale Sold out
Shipping calculated at checkout.

Only 1 left

IFM SM6020 Magnetic-Inductive Flow Meter — Magmeter with colour display and IO-Link for conductive liquids up to 35 l/min. 0.05...35 l/min, G 1/2, 2 x DI + analogue, IO-Link, colour display, 16 bar, IP 65/67.

Shipping & Returns

Same-day dispatch across UAE

Order before 2 PM (Sun–Thu). Next-day delivery to Dubai, Sharjah, Abu Dhabi. 2–4 days to other emirates.

7-day return window

Sealed, unused items can be returned within 7 days for full refund or replacement.

Compatibility-checked

Our specialists review every bulk quote to ensure the part fits your application before you commit.

MPN / SKU: SM6020

Also known as: IFM SM6020 flow meter / flow sensor / magmeter.

SM6020 Applications

The magnetic-inductive flow meter monitors the flow of conductive liquids such as water and hydrous media with a conductivity of at least 20 µS/cm. Having no moving parts, it measures flow, temperature and consumed quantity with a totaliser, showing values on a rotatable colour display. Two switching outputs, an analogue output and IO-Link communication provide flexible integration. With a G 1/2 process connection, 16 bar rating and IP 65 / IP 67 housing, it suits water and industrial fluid applications.

SM6020 Specifications

Brand IFM Product Type Magnetic-inductive flow meter for conductive liquids.
IFM Type Code SMR12XGXFRKG/US-100 Measuring range 0.05...35 l/min (0.003...2.1 m³/h)
Medium conductive liquids; water; hydrous media (≥ 20 µS/cm) Process connection G 1/2 external thread (DN15, flat seal)
Outputs 2 x digital (PNP/NPN); 1 x analogue (4...20 mA) IO-Link COM2, 38.4 kBaud, revision 1.1
Display colour display 1.44", 128 x 128 pixels; 2 x LED yellow Accuracy ±(0.8 % MW + 0.2 % MEW)
Operating voltage 18...30 V DC (SELV/PELV) Operating pressure 16 bar / 1.6 MPa
Medium temperature -20...90 °C Ambient temperature -20...60 °C
Protection rating IP 65; IP 67 Housing materials stainless steel (316/1.4408); PC; PBT+PC-GF30
Weight 717.2 g

SM6020 Datasheet & Manual

Download Datasheet & ManualIFM SM6020 · PDF · Official IFM document

SM6020 – Frequently Asked Questions (FAQ)

What is the IFM SM6020?

The IFM SM6020 is a magnetic-inductive flow meter (magmeter) for monitoring the flow of conductive liquids with no moving parts.

What is the measuring range of the IFM SM6020?

The IFM SM6020 measures flow from 0.05 to 35 l/min (0.003...2.1 m³/h).

What media can the IFM SM6020 measure?

The IFM SM6020 measures conductive liquids such as water and hydrous media with a conductivity of at least 20 µS/cm.

What process connection does the IFM SM6020 have?

The IFM SM6020 has a G 1/2 external thread process connection (DN15, flat seal).

What outputs does the IFM SM6020 provide?

The IFM SM6020 provides 2 digital outputs (PNP/NPN), 1 analogue output (4...20 mA) and IO-Link communication (COM2, 38.4 kBaud, revision 1.1).

What accuracy does the IFM SM6020 have?

The IFM SM6020 has a measuring accuracy of ±(0.8 % MW + 0.2 % MEW).

What is the pressure rating of the IFM SM6020?

The IFM SM6020 is rated for an operating pressure of 16 bar (1.6 MPa).

What supply voltage does the IFM SM6020 need?

The IFM SM6020 operates on 18...30 V DC (SELV/PELV).
