• Schmersal - TV12H 236-11Z-RMS-2088
1 1

TV12H 236-11Z-RMS-2088 Schmersal Two-roller lever Thermoplastic 2.5 mm² Limit Switch 46 mm*30 mm

TV12H 236-11Z-RMS-2088 Schmersal Two-roller lever Thermoplastic 2.5 mm² Limit Switch 46 mm*30 mm

SKUTV12H 236-11Z-RMS-2088BrandSchmersal
AED 178.00
AED 178.00
Sale Sold out
Shipping calculated at checkout.

The Schmersal TV12H 236-11Z-RMS-2088 is a reliable industrial limit switch designed with a two-roller lever actuator. Engineered for durability, it features a thermoplastic housing to withstand demanding environments.

View full details

Buying for a project?

Custom pricing on bulk orders & project quotes

Our specialists confirm compatibility, check stock across our brand network, and respond with a formal quote within one business day.

  • Brand: Schmersal
  • Actuator Type: Two-roller lever
  • IP Rating: IP65, IP67
  • Maximum Current: 10 A
  • Housing Material: Thermoplastic
  • Connection Type: 2.5 mm²
  • Series: TV12H 236
  • Contact Type: 1 NO contact, 1 NC contacts
  • Length: 46 mm
  • Maximum Operating Temperature: +80 °C
  • Width: 30 mm
  • Standards Met: EN 50047
  • Depth: 108.5 mm
  • Mechanical Life: 20,000,000 Operations
  • Mounting Orientation: Repositionable by 4 x 90°
