- Brand
- Schmersal
- Actuator Type
- Plunger
- IP Rating
- IP65
- Maximum Current
- 16 A
- Housing Material
- Metal
- Maximum AC Voltage
- 400 V
- Connection Type
- 2.5 mm²
- Series
- TS 422-01Y
ParameterValue
- Action Type
- Mechanical
- Contact Type
- With double break
- Length
- 63 mm
- Maximum Operating Temperature
- +90 °C
- Width
- 106 mm
- Standards Met
- EN IEC 60947-5-1
- Depth
- 97 mm
- Mechanical Life
- 10,000,000 Operations
ParameterValue
