• Schmersal - T4S 256-11ZUE-2638
1 1

T4S 256-11ZUE-2638 Schmersal Roller lever Metal 1 Cable entry M 20 x 1.5 Limit Switch 31 mm*58 mm

T4S 256-11ZUE-2638 Schmersal Roller lever Metal 1 Cable entry M 20 x 1.5 Limit Switch 31 mm*58 mm

SKUT4S 256-11ZUE-2638BrandSchmersal
AED 91.00
AED 91.00
Sale Sold out
Shipping calculated at checkout.

The Schmersal T4S 256-11ZUE-2638 is a reliable industrial limit switch designed with a roller lever actuator. Engineered for durability, it features a metal housing to withstand demanding environments.

View full details
ParameterValue
Brand
Schmersal
Actuator Type
Roller lever
IP Rating
IP65, IP67
Maximum Current
10 A
Housing Material
Metal
Maximum AC Voltage
500 V
Connection Type
1 Cable Entry M20x1.5
Series
T4VH 335
ParameterValue
Contact Type
1 NO contact, 1 NC contacts
Length
31 mm
Maximum Operating Temperature
+80 °C
Width
58 mm
Standards Met
EN 50041
Depth
90.5 mm
Mechanical Life
20,000,000 Operations
Operating Force
9 N
