- Accessory Type
- mounting bracket: 4; slot nuts: 4; Nuts
- Brand
- ifm
- Dimensions
- 1113 x 28 x 30
- Length
- 1113 mm
- Material
- housing: aluminium; front pane: PC
- Series
- OY047S
- Supply Voltage
- 24 DC
- Maximum Response Time
- 14.0 ms
ParameterValue
- Beam Resolution
- 30 mm
- Safety Type
- Type 4
- SIL IEC 61508
- SIL 3
- PL EN ISO 13849-1
- PL e
- Protective Height
- 1060 mm
- Maximum Scanning Distance
- 3...12
- Terminal Type
- 1 x M12; Coding: A; Maximum Cable Length: 100 m; For Wire Cross-Section 0.34 mm²
ParameterValue
Being a UAE company, our UAE shipments are subject to tariffs. Under DDP (Delivered Duty Paid), all applicable tariffs and fees are calculated and paid upfront at checkout.
Same-day dispatch across UAE
Order before 2 PM (Sun–Thu). Next-day delivery to Dubai, Sharjah, Abu Dhabi. 2–4 days to other emirates.
7-day return window
Sealed, unused items can be returned within 7 days for full refund or replacement.
Compatibility-checked
Our specialists review every bulk quote to ensure the part fits your application before you commit.
