- Accessory Type
- mounting bracket: 6; slot nuts: 6
- Brand
- ifm
- Dimensions
- 1136 x 50 x 60
- Length
- 1136 mm
- Material
- housing: aluminium; front pane: PC
- Series
- OY903S
- Supply Voltage
- 24 DC
- Maximum Response Time
- 10.5 ms
ParameterValue
- Number of Beams
- 4
- Safety Type
- Type 4
- SIL IEC 61508
- SIL 3
- PL EN ISO 13849-1
- PL e
- Protective Height
- 910 mm
- Maximum Scanning Distance
- 0...6
- Terminal Type
- 1 x M12; Coding: A; Maximum Cable Length: 100 m; For Wire Cross-Section 1 mm²
ParameterValue
