Waircom MHCT4 - Series M 2/2 N.C. Tapper Mechanical Valve (Ø4 bottom ported)

Waircom MHCT4 - Series M 2/2 N.C. Tapper Mechanical Valve (Ø4 bottom ported)

SKUMHCT4BrandWaircom
AED 69.00
AED 69.00
Sale Sold out
Shipping calculated at checkout.

The Waircom MHCT4 is a high-performance 2/2 N.C. mechanical valve from the rugged Series M range. Engineered for reliable micro-pneumatic control via a mechanical Swivel Lever actuator, this compact valve requires a 7 N actuation force to deliver an efficient flow rate of 83 Nl/min. The structural assembly consists of an anodized aluminium alloy body paired with durable nbr seals. Standard fluid connections are optimized via Ø4 bottom ported configurations, supporting stable system pressure ranges between 2 – 10 bar.

View full details
ParameterValue
Brand
Waircom
Series
Series M
Function
2/2 N.C.
Control Type
Tapper
Actuator Type
Swivel Lever
Port Size
Ø4 bottom ported
Nominal Bore
Ø2.5 mm
ParameterValue
Actuation Force
7 N at 6 bar
Flow Rate
83 Nl/min at 6 bar
Body Material
Anodized aluminium alloy
Seals
NBR
Operating Pressure
2 – 10 bar
Operating Temperature
0 – +60 (–20 with dry air) °C
ATEX Available
Yes
