2 Inch Flange AODD Pumps BA50CI-C991-C - Cast Iron Body Santoprene Diaphragm -BSK

SKUBA50CI-C991-CBrandBSK

AED 4,655.00

Sale Sold out

Shipping calculated at checkout.

Quantity

The BA50CI-C991-C is a high-performance, air-operated double diaphragm (AODD) pump constructed with a durable cast iron body and a chemically resistant Santoprene diaphragm. Designed for mining and heavy industrial applications, this pump is engineered to reliably transfer abrasive fluids and industrial liquids in demanding mining and heavy industrial environments. With a maximum flow rate of 667 L/Min and a maximum suction lift of 6.2 m, it provides efficient and safe operation for a wide range of applications

View full details

Buying for a project?

Custom pricing on bulk orders & project quotes

Our specialists confirm compatibility, check stock across our brand network, and respond with a formal quote within one business day.

Wetted Material: Cast Iron
Seat Material: Santoprene
Ball Material: Santoprene
Diaphragm Material: Santoprene
O-ring Materials: NBR
Discharge Port: Tri-Clamp
Fluid Outlet: 2"
Fluid Inlet: 2"
Max Flow: 680 L/Min

Max Suction Lift-Dry: 8.2 m
Max Air Pressure: 8.3 bar
Weight: 32.5kg
Noise: <78dB
Temperature Range: -40Â°C to 107.2Â°C
Dimensions/Size: 385Ã—515Ã—375mm
Color/Finish: Cast Iron
Applications/Industry: Sanitary Processing

Product Features

Cast Iron Body Material: Provides exceptional durability and strength, ensuring maximum longevity and reliability in heavy-duty sanitary processing environments.
Santoprene Diaphragm Material: Offers superior compatibility and lasting performance with fluids like food products, beverages, and sanitary process fluids in high-flow applications.
680 L/Min Max Flow: Enables highly efficient and rapid high-volume sanitary fluid transfer, large-scale food processing, and industrial-scale sanitary handling operations.
Self-Priming & Can Run Dry: Reduces downtime and prevents damage, critical for continuous high-volume sanitary processing and automated food production systems.
Tri-Clamp Sanitary Connections: Provides quick-disconnect sanitary connections for easy cleaning, maintenance, and compliance with food industry hygiene standards.
Seal-Less, Leak-Proof Design: Eliminates the risk of product contamination and maintains sanitary conditions in high-volume food processing operations.
Air-Operated (Intrinsically Safe): Safe for sanitary processing environments where electrical equipment may pose contamination risks in high-volume operations.
Heavy-Duty 2" Tri-Clamp Design: Optimized for high-volume sanitary flow capacity while maintaining easy cleaning and sanitary compliance.
CIP/SIP Compatible: Designed for Clean-in-Place and Sterilize-in-Place procedures standard in high-volume food processing facilities.
Industrial Sanitary Construction: Heavy-duty design meeting sanitary processing requirements for large-scale food and beverage operations.

Applications & Industries

Large-Scale Food Processing: High-volume transfer of food products, sauces, fruit concentrates, and food ingredients in industrial food production facilities requiring sanitary connections.
Industrial Beverage Production: High-capacity handling of juices, syrups, beer, wine, and beverage concentrates in large-scale bottling and packaging operations with sanitary requirements.
Dairy Processing Plants: High-volume transfer of milk, cream, dairy ingredients, and dairy products while maintaining sanitary conditions and easy cleaning capabilities.
Industrial Food Service: Large-scale pumping of cooking ingredients, sauces, and liquid food products in commercial food service and catering operations.
Sanitary Chemical Processing: High-volume handling of food-grade cleaning solutions, sanitizers, and CIP chemicals in large food processing facility maintenance.
Note: The BA50CI-C991-C's cast iron construction with tri-clamp sanitary connections provides maximum durability for high-volume sanitary applications. The tri-clamp design ensures easy cleaning, maintenance, and compliance with food industry hygiene standards while the heavy-duty construction supports continuous operation in demanding food processing environments requiring both sanitary compliance and industrial-grade reliability.

Why Choose This Pump?

The BA50CI-C991-C from BSK Fluid Technology combines heavy-duty cast iron construction with sanitary tri-clamp connections and proven AODD pump technology to deliver unmatched strength, sanitary compliance, and reliability for the most demanding high-volume food processing and sanitary applications.

Key Product Highlights:

Heavy-Duty Sanitary Construction: Cast iron body with tri-clamp connections providing maximum durability and sanitary compliance for food processing
Tri-Clamp Sanitary Design: Quick-disconnect sanitary connections ensuring easy cleaning, maintenance, and compliance with food industry standards
High-Volume Sanitary Performance: 680 L/Min capacity through 2" tri-clamp ports for efficient large-scale food processing operations
CIP/SIP Compatible: Designed for standard food industry cleaning and sterilization procedures
Proven Heavy-Duty AODD Technology: Self-priming, seal-less operation preventing product contamination in high-volume applications
Industrial Food Processing Durability: Built for continuous operation in demanding food processing environments
Safe Sanitary Operation: Air-powered design eliminates electrical contamination risks in food processing facilities
Easy Maintenance Design: Tri-clamp connections facilitate quick disassembly for thorough cleaning and maintenance

The BA50CI-C991-C is the ideal choice for large-scale food processing, industrial beverage production, dairy processing plants, and commercial food service where heavy-duty construction, sanitary compliance, high-volume capacity, and easy cleaning are essential for meeting food safety regulations and ensuring continuous operation in demanding sanitary processing environments.
