UIT512 - ifm threaded type Proximity Sensor

SKU UIT512Brand ifm

AED 1,968.00 excl. VAT

Shipping calculated at checkout.

In stock

The UIT512 is a highly reliable threaded type proximity sensor engineered by ifm for precision industrial automation. Featuring a 350...6000; (Target: 400 x 400 mm)mm sensing range and a rugged stainless steel (316L/1.4404) housing, this sensor is built to withstand harsh environments with an IP67... Read more

Pickup available
at Creative Ajman Showroom

Usually ready in 24 hours

View store
information

Description

The UIT512 is a highly reliable threaded type proximity sensor engineered by ifm for precision industrial automation. Featuring a 350...6000; (Target: 400 x 400 mm)mm sensing range and a rugged stainless steel (316L/1.4404) housing, this sensor is built to withstand harsh environments with an IP67 protection rating. It operates on a 10...30 DC supply voltage, and a NPN output with normally open / normally closed; (parameterisable) switching, making it an ideal proximity switch for your manufacturing and control systems.

Specification

Parameter	Value
Brand	ifm
Thread Size	M30 x 1.5
Body Style	threaded type
Output Type	NPN
Detection Range	350...6000 (Target 400 x 400 mm)
Output Function	normally open / normally closed; (parameterisable)
Connection Type	1 x M12; coding A
Supply Voltage	10...30 DC
IP Rating	IP67

Parameter	Value
Housing Material	stainless steel (316L/1.4404); PA; epoxy glass ceramics
Maximum DC Voltage	2.2
Minimum Operating Temperature	-20°C
Switching Current	100
Switching Frequency	1 Hz
Maximum Operating Temperature	70°C
Standards Met	EN 61000-4-2 ESD \| 4 kV CD / 8 kV AD; EN 61000-4-3 HF radiated \| 3 V/m; EN 61000-4-4 Burst \| 2 kV; EN 61000-4-6 HF conducted \| 3 V; EN 55011 \| Class A
Series	UIT512
Short Circuit Overload Protection	yes
