Waircom UDS12 TQ/KUC - UDS CETOP Size 12 5/2 monostable Pilot Actuated Valve

Waircom UDS12 TQ/KUC - UDS CETOP Size 12 5/2 monostable Pilot Actuated Valve

SKUUDS12 TQ/KUCBrandWaircom
AED 293.00
AED 293.00
Sale Sold out
Shipping calculated at checkout.

In stock

The Waircom UDS12 TQ/KUC is a high-performance 5/2 monostable directional control valve from the specialized UDS CETOP Size 12 range. Natively designed to mount directly onto bases meeting the historic ex CETOP RP 32 P interface standard, this valve relies on a Pneumatic spring and Solenoid (direct pilot, with ULCSV/R) pneumatic pilot control system for reliable shifting. The assembly features an anodized aluminium alloy body that delivers a precise 950 Nl/min capacity, optimized for system pressures between 2.5 to 10 bar (monostable) and temperatures of 0 to +70 °C (-20 °C with dry air).

View full details
  • Brand: Waircom
  • Size: Size 12
  • Interface Standard: ex CETOP RP 32 P
  • Function: 5/2 monostable
  • Actuation: Solenoid actuated (requires ULCSV/R pilot solenoid valve)
  • Left (Port 14) Control: Pneumatic spring
  • Right (Port 12) Control: Solenoid (direct pilot, with ULCSV/R)
  • Flow Rate: 950 Nl/min
  • Operating Pressure: 2.5 to 10 bar (monostable)
  • Working Temperature: 0 to +70 °C (-20 °C with dry air)
  • Body Material: Anodized aluminium alloy
  • Piloting Solenoid: ULCSV/R (Series UL, sold separately — see E_UL.xlsx)
