Waircom UDS12 SUC/SUC - UDS CETOP Size 12 5/3 closed centre Pilot Actuated Valve

Waircom UDS12 SUC/SUC - UDS CETOP Size 12 5/3 closed centre Pilot Actuated Valve

SKUUDS12 SUC/SUCBrandWaircom
AED 511.00
AED 511.00
Sale Sold out
Shipping calculated at checkout.

The Waircom UDS12 SUC/SUC is a high-performance 5/3 closed centre directional control valve from the specialized UDS CETOP Size 12 range. Natively designed to mount directly onto bases meeting the historic ex CETOP RP 32 P interface standard, this valve relies on a Solenoid direct — closed centre (with ULCSV/R) and Solenoid direct — closed centre (with ULCSV/R) pneumatic pilot control system for reliable shifting. The assembly features an anodized aluminium alloy body that delivers a precise 950 Nl/min capacity, optimized for system pressures between 2 to 10 bar and temperatures of 0 to +70 °C (-20 °C with dry air).

View full details
ParameterValue
Brand
Waircom
Size
Size 12
Interface Standard
ex CETOP RP 32 P
Function
5/3 closed centre
Actuation
Solenoid actuated (requires ULCSV/R pilot solenoid valve)
Left (Port 14) Control
Solenoid direct — closed centre (with ULCSV/R)
ParameterValue
Right (Port 12) Control
Solenoid direct — closed centre (with ULCSV/R)
Flow Rate
950 Nl/min
Operating Pressure
2 to 10 bar
Working Temperature
0 to +70 °C (-20 °C with dry air)
Body Material
Anodized aluminium alloy
Piloting Solenoid
ULCSV/R (Series UL, sold separately — see E_UL.xlsx)
