Waircom UDS05 SR/SR - UDS CETOP Size 05 5/3 closed centre Pilot Actuated Valve

Waircom UDS05 SR/SR - UDS CETOP Size 05 5/3 closed centre Pilot Actuated Valve

SKUUDS05 SR/SRBrandWaircom
AED 272.00
AED 272.00
Sale Sold out
Shipping calculated at checkout.

The Waircom UDS05 SR/SR is a high-performance 5/3 closed centre directional control valve from the specialized UDS CETOP Size 05 range. Natively designed to mount directly onto bases meeting the historic ex CETOP RP 32 P interface standard, this valve relies on a Pneumatic pilot — closed centre and Pneumatic pilot — closed centre pneumatic pilot control system for reliable shifting. The assembly features an anodized aluminium alloy body that delivers a precise 415 Nl/min capacity, optimized for system pressures between 2 to 10 bar and temperatures of 0 to +70 °C (-20 °C with dry air).

View full details
ParameterValue
Brand
Waircom
Size
Size 05
Interface Standard
ex CETOP RP 32 P
Function
5/3 closed centre
Actuation
Pilot actuated (pneumatic only)
Left (Port 14) Control
Pneumatic pilot — closed centre
ParameterValue
Right (Port 12) Control
Pneumatic pilot — closed centre
Flow Rate
415 Nl/min
Operating Pressure
2 to 10 bar
Working Temperature
0 to +70 °C (-20 °C with dry air)
Body Material
Anodized aluminium alloy
