Z-15GW2-B7-K - Omron Roller-Lever Thermosetting Resin Limit Switch, NO/NC (IP00)

Z-15GW2-B7-K - Omron Roller-Lever Thermosetting Resin Limit Switch, NO/NC (IP00)

SKUZ-15GW2-B7-KBrandOmron
AED 73.00
AED 73.00
Sale Sold out
Shipping calculated at checkout.

The Z-15GW2-B7-K is a dependable limit switch from Omron, part of the Roller-Lever series. Designed with a Roller-Lever actuator and a durable Thermosetting Resin housing, this switch provides NO/NC contact configuration with IP00 environmental protection. Rated for 15000 mA at 500 V with Snap-Action operation, designed for accurate position detection and end-of-travel switching in industrial machinery, conveyor systems, and automated production lines.

View full details
ParameterValue
Brand
Omron
Action Type
Snap-Action
Actuator Type
Roller-Lever
Depth
17.45 mm
Housing Material
Thermosetting Resin
IP Rating
IP00
Length
49.2 mm
Maximum AC Voltage
500 V
ParameterValue
Maximum Current
15000 mA
Maximum DC Voltage
250 V
Maximum Operating Temperature
80 °C
Mechanical Life
20000000Operations
Minimum Operating Temperature
-25 °C
Normal State Configuration
NO/NC
Pole and Throw Configuration
SPDT
Width
29.4 mm
