- Brand
- Omron
- Thread Size
- M8
- Sensor Technology
- Inductive
- Detection Range
- 8 mm
- Body Style
- Threaded Barrel
- Output Function
- NO
- Digital Switching Output Type
- PNP
- Connection Type
- M12
- Supply Voltage
- 10 ? 30 V dc
- IP Rating
- IP67, IP67G, IP69K
- Length
- 37.8mm
- Mounting Type
- Non-Flush
- Width
- 8mm
- Housing Material
- Stainless Steel
ParameterValue
- Maximum dc Voltage
- 30V
- Minimum Operating Temperature
- -25°C
- Communication Protocol
- IO-LINK
- Maximum Operating Temperature
- +70°C
- Depth
- 13mm
- Shielding
- Unshielded
- Maximum Switching Frequency
- 500Hz
- Switching Current
- 16 mA
- Reverse Polarity Protection
- Yes
- Switching Frequency
- 500 Hz
- Standards Met
- CE
- Series
- E2E-NEXT
- Short Circuit Overload Protection
- Yes
ParameterValue
