- Brand
- Omron
- Thread Size
- M12
- Sensor Technology
- Inductive
- Detection Range
- 4 mm
- Body Style
- Threaded Barrel
- Output Function
- NO
- Digital Switching Output Type
- NPN
- Connection Type
- M12
- Supply Voltage
- 10 ? 30 V dc
- Length
- 47.1mm
- IP Rating
- IP67, IP67G, IP69K
- Mounting Type
- Flush
- Width
- 12mm
- Housing Material
- Brass
ParameterValue
- Maximum dc Voltage
- 30V
- Minimum Operating Temperature
- -25°C
- Maximum Switching Frequency
- 1kHz
- Communication Protocol
- IO-LINK
- Switching Current
- 16 mA
- Reverse Polarity Protection
- Yes
- Maximum Operating Temperature
- +70°C
- Switching Frequency
- 1 kHz
- Series
- E2E-NEXT
- Short Circuit Overload Protection
- Yes
- Depth
- 17mm
- Shielding
- Shielded
- Country of Origin
- China
ParameterValue
