The KTE101 is a highly reliable threaded type proximity sensor engineered by ifm for precision industrial automation. Featuring a rugged PA housing, this sensor is built to withstand harsh environments with an IP65 protection rating. It operates on a 8...32 DC supply voltage, and a PNP/NPN; (parameterisable) output with normally open / normally closed; (parameterisable) switching, making it an ideal proximity switch for your manufacturing and control systems.

View full details

Buying for a project?

Custom pricing on bulk orders & project quotes

Our specialists confirm compatibility, check stock across our brand network, and respond with a formal quote within one business day.

Brand: ifm
Thread Size: M22 x 1
Body Style: threaded type
Output Type: PNP/NPN (Parameterisable)
Output Function: normally open / normally closed; (parameterisable)
Connection Type: 1 x M12; coding: A
Supply Voltage: 8...32 DC
IP Rating: IP65; IP67; (IP69K on the front)

Housing Material: housing: PA; lock nut: PBT; symbol disc: PA; Flat seal: NR
Maximum DC Voltage: 1.5
Minimum Operating Temperature: -30°C
Switching Current: 200
Maximum Operating Temperature: 65°C
Standards Met: EN 61000-4-2 ESD | 4 kV CD / 8 kV AD; EN 61000-4-3 HF radiated | 10 V/m / 3 V/m; EN 61000-4-4 Burst | 2 kV; EN 61000-4-6 HF conducted | 10 V; IEC 61000-6-3, EN 55011 | (Class B); IEC 61000-4-5 Surge | 1 kV (L+ to L- , 42 Ω, 0,5 µF) / 0,5 kV (all cables to L- , 42 Ω, 0,5 µF); |
Series: KTE101
Short Circuit Overload Protection: yes
