IN5451 - ifm rectangular Proximity Sensor

Name: IN5451 - ifm rectangular Proximity Sensor
Brand: ifm
SKU: IN5451
Price: 381.00 AED
Availability: InStock

SKUIN5451Brandifm

AED 381.00

Sale Sold out

Shipping calculated at checkout.

Quantity

The IN5451 is a highly reliable rectangular proximity sensor engineered by ifm for precision industrial automation. Featuring a 7mm sensing range and a rugged PBT housing, this sensor is built to withstand harsh environments with an IP67 protection rating. It operates on a 10...36 DC; ("supply class 2" according to UL) supply voltage, and a PNP output with normally open switching, making it an ideal proximity switch for your manufacturing and control systems.

View full details

Buying for a project?

Custom pricing on bulk orders & project quotes

Our specialists confirm compatibility, check stock across our brand network, and respond with a formal quote within one business day.

Brand: ifm
Thread Size: M8 x 1
Body Style: rectangular
Output Type: PNP
Detection Range: 7
Output Function: normally open
Connection Type: 1 x M8, straight; coding: A
Cable Length: 0.3 m
Supply Voltage: 10...36 DC; ("supply class 2" according to UL)
IP Rating: IP67

Mounting Type: Non-Flush
Housing Material: PBT
Maximum DC Voltage: 2.5
Minimum Operating Temperature: 0°C
Switching Current: 250
Switching Frequency: 300 Hz
Maximum Operating Temperature: 60°C
Standards Met: EN 61000-4-2 ESD | 8 kV CD / 15 kV AD; EN 61000-4-3 HF radiated | 10 V/m; EN 61000-4-4 Burst | 2 kV; EN 61000-4-6 HF conducted | 10 V; EN 55011 emission | class B
Series: IN5451
Short Circuit Overload Protection: yes
