IB5171 - ifm cylindrical Proximity Sensor

Name: IB5171 - ifm cylindrical Proximity Sensor
Brand: ifm
SKU: IB5171
Price: 548.00 AED
Availability: InStock

SKUIB5171Brandifm

AED 548.00

Sale Sold out

Shipping calculated at checkout.

Quantity

The IB5171 is a highly reliable cylindrical proximity sensor engineered by ifm for precision industrial automation. Featuring a 30mm sensing range and a rugged PBT housing, this sensor is built to withstand harsh environments with an IP67 protection rating. It operates on a 10...30 DC supply voltage, and a PNP output with complementary switching, making it an ideal proximity switch for your manufacturing and control systems.

View full details

Buying for a project?

Custom pricing on bulk orders & project quotes

Our specialists confirm compatibility, check stock across our brand network, and respond with a formal quote within one business day.

Brand: ifm
Thread Size: M12 x 1
Body Style: cylindrical
Output Type: PNP
Detection Range: 30
Output Function: complementary
Connection Type: 1 x M12; coding: A; Locking: brass, white bronze coated; Contacts: gold-plated
Supply Voltage: 10...30 DC
IP Rating: IP67
Mounting Type: Non-Flush

Housing Material: housing: PBT; sensing face: PBT orange; clamp: PBT black
Maximum DC Voltage: 2.5
Minimum Operating Temperature: -25°C
Switching Current: 200
Switching Frequency: 350 Hz
Maximum Operating Temperature: 80°C
Standards Met: EN 60947-5-2 | ; EN 61000-4-2 ESD | 4 kV CD / 8 kV AD; EN 61000-4-3 HF radiated | 10 V/m; EN 61000-4-4 Burst | 2 kV; EN 61000-4-5 Surge | 0,5 kV line to line, Ri: 2 Ohm; EN 61000-4-6 HF conducted | 10 V; EN 55011 | class B
Series: IB5171
Short Circuit Overload Protection: yes
