IFM EVF001 - Connection Cable with Socket, M12 4-pin, 5 m MPPE

Q: What is the connector on IFM EVF001?

IFM EVF001 has one straight, A-coded M12 socket with 4 gold-plated contacts and a stainless steel locking sleeve.

Q: How long is the IFM EVF001 cable?

The IFM EVF001 cable is 5 m long with a 4 x 0.34 mm² cross section and a 4.9 mm outer diameter.

Q: What is the cable material of IFM EVF001?

IFM EVF001 uses a halogen-free, silicone-free MPPE jacket in grey, suitable for hygienic and wet food-industry areas.

Q: What is the IP rating of IFM EVF001?

IFM EVF001 is rated IP65, IP67, IP68 and IP69K for protection against dust, immersion and high-pressure washdown.

Q: What voltage and current does IFM EVF001 handle?

IFM EVF001 is rated for < 250 V AC / < 300 V DC operating voltage and a maximum current load of 4 A.

Q: What temperature range does IFM EVF001 support?

IFM EVF001 operates from -25 to 100 °C when static, and its bending radius is min. 10 x cable diameter for drag chain use.

Q: Is IFM EVF001 suitable for drag chains?

Yes, IFM EVF001 offers drag chain suitability with more than 1 million bending cycles at min. 10 x cable diameter.

SKUEVF001BrandIFM

AED 89.00

Sale Sold out

Shipping calculated at checkout.

Only 10 left

Quantity

IFM EVF001 Connection Cable with Socket — Halogen-free MPPE cable for hygienic food-industry washdown zones. M12 socket, 4-pin, straight, A-coded, 5 m, MPPE, IP69K, gold-plated contacts.

Shipping & Returns

Same-day dispatch across UAE

Order before 2 PM (Sun–Thu). Next-day delivery to Dubai, Sharjah, Abu Dhabi. 2–4 days to other emirates.

7-day return window

Sealed, unused items can be returned within 7 days for full refund or replacement.

Compatibility-checked

Our specialists review every bulk quote to ensure the part fits your application before you commit.

MPN / SKU: EVF001

Also known as: IFM EVF001 cable / cordset / connecting cable.

EVF001 Applications

Designed for hygienic and wet areas in the food industry, this connecting cable features a silicone-free, halogen-free MPPE jacket that withstands washdown environments. Gold-plated contacts ensure reliable signal transmission, while its drag chain suitability supports use on moving machine parts. The A-coded M12 socket with stainless steel locking sleeve delivers IP65, IP67, IP68 and IP69K sealing for demanding production lines.

EVF001 Specifications

Brand	IFM	Product Type	Connecting cable with socket
IFM Type Code	ADOGH040VAS0005P04	Connection	M12 socket, straight
Coding	A-coded	Number of contacts	4
Cable length	5 m	Cable material	MPPE, halogen-free
Cross section	4 x 0.34 mm²	Cable diameter	4.9 mm
Operating voltage	< 250 V AC / < 300 V DC	Max. current load	4 A
Protection rating	IP 65 / IP 67 / IP 68 / IP 69K	Ambient temperature	-25...100 °C
Bending radius	min. 10 x cable diameter	Jacket colour	grey
Weight	165.9 g
