IFM EVC008 Connection Cable with Socket — 5 m M12 4-pole angled socket, PUR drag-chain cable, oils/coolants resistant, IP69K. M12 4-pole angled socket, 5 m PUR halogen-free cable (4 x 0.34 mm²), drag-chain suitable, gold-plated, 10...36 V DC, IP69K, -25...90 °C.
Shipping & Returns
Same-day dispatch across UAE
Order before 2 PM (Sun–Thu). Next-day delivery to Dubai, Sharjah, Abu Dhabi. 2–4 days to other emirates.
7-day return window
Sealed, unused items can be returned within 7 days for full refund or replacement.
Compatibility-checked
Our specialists review every bulk quote to ensure the part fits your application before you commit.
MPN / SKU: EVC008
Also known as: IFM EVC008 cable / cordset / connecting cable.
EVC008 Applications
The IFM EVC008 is a connection cable with M12 socket used to wire sensors and actuators to controllers in factory automation. It is suited for machine tools and applications exposed to coolants and lubricants, and for moving cable carriers thanks to its drag-chain-rated PUR jacket. The 5 m 4-pole angled socket provides a permanent, tool-free reliable seal, gold-plated contacts and a locking coupling ring give vibration and shock resistance, and clearly visible LEDs indicate switching status. Rated to IP69K for harsh, washdown environments.
EVC008 Specifications
Brand
IFM
Product Type
Connecting cable with socket
IFM Type Code
ADOAH043MSS0005H04
Connector
M12, angled, A-coded, 4 gold-plated contacts
Cable
5 m PUR, halogen-free, black, Ø 4.3 mm, 4 x 0.34 mm²
What connector and cable length does the IFM EVC008 have?
The EVC008 has one M12 angled socket, A-coded, with 4 gold-plated contacts, on a 5 m cable.
What voltage and current is the IFM EVC008 rated for?
The EVC008 is rated for 10...36 V DC with a maximum total current load of 4 A.
What is the conductor cross section of the IFM EVC008?
The EVC008 has 4 conductors of 0.34 mm2 each (4 x 0.34 mm2, 42 x diameter 0.1 mm).
What is the jacket material and cable diameter of the IFM EVC008?
The EVC008 cable jacket is PUR, halogen-free and black, with a cable diameter of 4.3 mm. It is free from silicone and halogen-free.
What is the IP rating of the IFM EVC008?
The EVC008 is rated to IP 65, IP 67, IP 68 and IP 69K.
What is the operating temperature range of the IFM EVC008?
The EVC008 has an operating temperature range of -25...90 degrees C.
Is the IFM EVC008 suitable for drag chains?
Yes, the EVC008 offers drag chain suitability with more than 5 million bending cycles, at a minimum bending radius of 10 x the cable diameter for flexible use.
What are the core colours of the IFM EVC008?
The EVC008 core colours are BK = black, BN = brown, BU = blue and WH = white.
