IFM KI6000 Capacitive Sensor — M30 adjustable 0.5...40 mm, IO-Link, signal display, high medium temperature. capacitive sensor, M30 x 1.5 housing, adjustable sensing range 0.5...40 mm, PNP NO/NC, IO-Link, 12-LED signal display, for position detection and level monitoring, IP69K.
Shipping & Returns
Same-day dispatch across UAE
Order before 2 PM (Sun–Thu). Next-day delivery to Dubai, Sharjah, Abu Dhabi. 2–4 days to other emirates.
7-day return window
Sealed, unused items can be returned within 7 days for full refund or replacement.
Compatibility-checked
Our specialists review every bulk quote to ensure the part fits your application before you commit.
MPN / SKU: KI6000
Also known as: IFM KI6000 proximity sensor / level sensor / level switch.
KI6000 Applications
The IFM KI6000 capacitive sensor detects objects and level through non-metallic walls with an adjustable range to 40 mm. IO-Link and a 12-LED signal display simplify setting the perfect switch point, and it handles high medium temperatures.
What is the sensing range of the IFM KI6000 capacitive sensor?
The KI6000 has an adjustable sensing range of 0.5...40 mm, with a factory setting of 25 mm (real sensing range 25 +/- 10 %).
Does the KI6000 support IO-Link?
Yes, the KI6000 supports IO-Link revision 1.1 with COM2 transmission at 38.4 kBaud, enabling configurable switch points, hysteresis adjustment and an operating hours counter.
What output does the KI6000 provide?
The KI6000 is a PNP sensor with a selectable normally open / normally closed switching output rated for 200 mA at a switching frequency of 30 Hz.
What voltage does the KI6000 operate on?
The KI6000 operates on 10...30 V DC with a current consumption of less than 22 mA, and includes reverse polarity and short-circuit protection.
What is the housing and thread of the KI6000?
The KI6000 has an M30 x 1.5 threaded housing (length 92 mm) made of PBT, PC and POM.
What temperatures can the KI6000 handle?
The KI6000 operates at an ambient temperature of -25...80 C and withstands a medium temperature up to -25...110 C.
What is the IP rating of the KI6000?
The KI6000 is rated IP 65, IP 67 and IP 69K.
What setting aids and displays does the KI6000 have?
The KI6000 has a yellow status LED, a green operation LED, and a 12-LED green optical setting aid, and connects via a single M12 A-coded 4-pin connector.
