- Brand
- Vishay
- Diode Configuration
- Single
- Nominal Zener Voltage
- 18V
- Number of Elements per Chip
- 1
- Mounting Type
- Surface Mount
- Maximum Power Dissipation
- 1 W
- Package Type
- DO-213AB
- Zener Type
- General Purpose
- Zener Voltage Tolerance
- ±5%
ParameterValue
- Pin Count
- 2
- Test Current
- 14mA
- Maximum Zener Impedance
- 20?
- Maximum Reverse Leakage Current
- 5µA
- Dimensions
- 2.6 (Dia.) x 5.2mm
- Minimum Operating Temperature
- -65 °C
- Maximum Operating Temperature
- +165 °C
- Automotive Standard
- AEC-Q101
- Country of Origin
- China
ParameterValue
