3 Inch AODD Pumps BA80AL-0TT3-A - Aluminium Body PTFE Diaphragm -BSK

Name: 3 Inch AODD Pumps BA80AL-0TT3-A - Aluminium Body PTFE Diaphragm -BSK
Brand: BSK
SKU: BA80AL-0TT3-A
Price: 10410.00 AED
Availability: InStock

SKUBA80AL-0TT3-ABrandBSK

AED 10,410.00

Sale Sold out

Shipping calculated at checkout.

Quantity

The BA80AL-0TT3-A is a high-performance, air-operated double diaphragm (AODD) pump constructed with a durable aluminum body and a chemically resistant PTFE diaphragm. Designed for corrosive fluid handling and chemical transfer, this pump is engineered to reliably transfer corrosive chemicals and aggressive fluids in demanding chemical processing and heavy industrial environments. With a maximum flow rate of 903 L/Min and a maximum suction lift of 5.3 m, it provides efficient and safe operation for a wide range of applications

View full details

Wetted Material: Aluminium
Seat Material: PTFE
Ball Material: PTFE
Diaphragm Material: PTFE
O-ring Materials: NBR
Discharge Port: BSP
Fluid Outlet: 3"
Fluid Inlet: 3"
Max Flow: 1400 L/Min
Max Suction Lift-Dry: 8.5 m
Max Air Pressure: 8.3 bar
Weight: 58.5kg
Noise: <80dB
Temperature Range: -40°C to 149°C
Dimensions/Size: 495×620×480mm
Color/Finish: Anodized Aluminium
Applications/Industry: Chemical Processing
Heavy-Duty Aluminum Body: Provides exceptional resistance to corrosion and robust durability, ensuring longevity and reliability in extreme high-volume aggressive chemical environments.
All-PTFE Wetted Parts Design: Provides maximum chemical compatibility and temperature resistance for the most demanding ultra-high-volume chemical applications.
PTFE Diaphragm Material: Offers superior chemical compatibility and temperature resistance for handling massive quantities of aggressive chemicals, acids, and high-temperature process fluids.
1400 L/Min Max Flow: Enables ultra-efficient and rapid massive-volume chemical processing, aggressive fluid transfer, and industrial-scale chemical handling operations.

Self-Priming & Can Run Dry: Reduces downtime and prevents damage, critical for continuous ultra-high-volume aggressive chemical processing operations.
Seal-Less, Leak-Proof Design: Eliminates the risk of costly leaks and protects the environment from massive volumes of aggressive chemicals in industrial-scale operations.
Air-Operated (Intrinsically Safe): Critical for ultra-high-volume hazardous chemical environments where electrical sparks could cause catastrophic reactions in massive-scale operations.
High Temperature Range (-40°C to 149°C): Handles high-temperature chemical processes and extreme operating conditions in massive-scale applications.
Maximum Chemical Resistance: PTFE construction provides unmatched compatibility with ultra-high volumes of aggressive acids, solvents, and corrosive chemicals.
Industrial-Scale 3" Port Design: Massive flow capacity design for the most demanding industrial chemical processing applications requiring maximum throughput.
Massive-Scale Chemical Processing: Ultra-high-volume handling of strong acids, caustic solutions, aggressive solvents, and corrosive chemical processing fluids in major industrial facilities.
Industrial High-Temperature Applications: Massive-scale processing of heated chemicals, high-temperature process fluids, and applications requiring operation up to 149°C with maximum throughput.
Major Pharmaceutical Manufacturing: Ultra-high-capacity transfer of active pharmaceutical ingredients, cleaning solvents, and process chemicals in large-scale pharmaceutical production facilities.
Industrial Semiconductor Manufacturing: Massive-volume handling of ultra-pure chemicals, aggressive etchants, and specialty processing fluids in major semiconductor fabrication facilities.
Bulk Chemical Production: Ultra-high-capacity processing of aggressive intermediates, specialty solvents, and bulk chemicals in major chemical manufacturing facilities.
Note: The BA80AL-0TT3-A's 3" port design with 1400 L/Min capacity and all-PTFE construction represents the ultimate in industrial-scale chemical processing capability. This model is specifically engineered for massive-volume aggressive chemical applications where maximum flow capacity, chemical compatibility, and temperature resistance are required for major industrial operations demanding the highest levels of performance and safety.
Industrial-Scale All-PTFE Construction: Maximum chemical compatibility with massive volumes of aggressive acids, caustic solutions, and corrosive chemicals
Ultra-High-Volume Capacity: Massive 1400 L/Min flow through 3" ports for industrial-scale chemical processing operations
Maximum Chemical Resistance: Unmatched compatibility with ultra-high volumes of aggressive chemicals in major industrial applications
Industrial-Grade Temperature Performance: Operates reliably across -40°C to 149°C for massive-scale high-temperature chemical processes
Proven Industrial AODD Technology: Self-priming, seal-less operation ideal for continuous massive-scale aggressive chemical handling
Heavy-Duty Industrial Construction: Built for continuous operation in the most demanding industrial chemical processing environments
Maximum Throughput Design: 3" port configuration delivering industry-leading flow rates for major chemical processing facilities
Industrial Safety Compliance: Intrinsically safe operation critical for massive-scale hazardous chemical environments
