- Brand
- TE Connectivity
- Series
- STRATO-THERM
- Insulation
- Uninsulated
- Inner Ring Diameter
- 3.68mm
- Outer Ring Diameter
- 5.54mm
- Minimum Wire Size mm²
- 0.26mm²
- Maximum Wire Size mm²
- 1.65mm²
- Minimum Wire Size (mm²)
- 0.26mm²
- Maximum Wire Size (mm²)
- 1.65mm²
- Minimum Wire Size AWG
- 22AWG
ParameterValue
- Maximum Wire Size AWG
- 16AWG
- Maximum Wire Size (AWG)
- 16AWG
- Minimum Wire Size (AWG)
- 22AWG
- Stud Size
- M3.5
- Contact Plating
- Nickel
- Contact Material
- Copper
- Thickness
- 0.79mm
- Overall Length
- 11.4mm
- Country of Origin
- United States
ParameterValue
