- Brand
- TE Connectivity
- Series
- PIDG
- Insulation
- Insulated
- Insulation Material
- Nylon
- Inner Ring Diameter
- 3.68mm
- Outer Ring Diameter
- 7.14mm
- Minimum Wire Size mm²
- 0.26mm²
- Maximum Wire Size mm²
- 1.65mm²
- Maximum Wire Size (mm²)
- 1.65mm²
- Minimum Wire Size (mm²)
- 0.26mm²
ParameterValue
- Minimum Wire Size AWG
- 22AWG
- Maximum Wire Size AWG
- 16AWG
- Maximum Wire Size (AWG)
- 16AWG
- Minimum Wire Size (AWG)
- 22AWG
- Stud Size
- M3.5
- Colour
- Red
- Contact Plating
- Tin
- Contact Material
- Copper
- Thickness
- 0.79mm
- Overall Length
- 20.24mm
ParameterValue
