PT3542 - Stainless Steel (316L/1.4404) Relative Pressure Sensor, IP67; IP69K (0 bar to 200 bar)

Name: PT3542 - Stainless Steel (316L/1.4404) Relative Pressure Sensor, IP67; IP69K (0 bar to 200 bar)
Brand: ifm
SKU: PT3542
Price: 752.00 AED
Availability: InStock

SKUPT3542Brandifm

AED 752.00

Sale Sold out

Shipping calculated at checkout.

Quantity

The PT3542 is a high-precision pressure sensor engineered for reliable relative pressure measurement in demanding industrial applications. Encased in a durable stainless steel (316L/1.4404) housing and featuring IP67; IP69K protection, this sensor accurately reads pressures ranging from 0 bar to 200 bar. Operating on a 8.5...36 DC supply voltage and delivering a precise 4...20 mA analogue output, it provides seamless integration into your process control and automated monitoring systems.

View full details

Buying for a project?

Custom pricing on bulk orders & project quotes

Our specialists confirm compatibility, check stock across our brand network, and respond with a formal quote within one business day.

Brand: ifm
Housing Material: Stainless Steel (316L/1.4404)
IP Rating: IP67; IP69K
Maximum Operating Temperature: 90°C
Minimum Operating Temperature: -25°C
Series: PT
Standards/Approvals: EMC: EN 61000-4-2 ESD | 4 kV CD / 8 kV AD; EN 61000-4-3 HF radiated | 10 V/m; EN 61000-4-4 Burst | 4 kV coupling clamp; EN 61000-4-5 Surge | 1 kV signal for DC units; EN 61000-4-6 HF conducted | 10 V; Shock resistance: DIN IEC 68-2-27 | 50 g (11 ms); Vibration resistance: DIN IEC 68-2-6 | 20 g (10...2000 Hz); Pressure Equipment Directive: Sound engineering practice; can be used for group 2 fluids; group 1 fluids on request
Supply Voltage: 8.5...36 DC
Electrical Connection: 1 x M12; coding: A
