- Brand
- Molex
- Gender
- Female
- For Use With
- Mini-Fit Jr, Mini-Fit TPA and Mini-Fit BMI Connector Housings
- Series
- Mini-Fit Plus
- Maximum Wire Size mm²
- 1.3mm²
- Termination Method
- Crimp
- Maximum Wire Size (mm²)
- 1.3mm²
- Minimum Wire Size AWG
- 16AWG
- Contact Plating
- Tin
- Minimum Wire Size (AWG)
- 16AWG
ParameterValue
- Maximum Wire Size AWG
- 16AWG
- Contact Material
- Copper Nickel Silicon Alloy
- Maximum Wire Size (AWG)
- 16AWG
- Series Number
- 45750
- Maximum Contact Resistance
- 10m?
- Minimum Operating Temperature
- -55°C
- Maximum Current
- 13A
- Maximum Operating Temperature
- +105°C
- Country of Origin
- United States
ParameterValue
