- Brand
- Pizzato
- IP Rating
- IP67
- Series
- FC
- Maximum Operating Temperature
- +80°C
- Minimum Operating Temperature
- -25°C
- Length
- 56mm
- Width
- 30mm
- Depth
- 45.5mm
- Housing Material
- Metal
- Action Type
- Slow Action
- Actuator Type
- Right Transversal Rope Pull
ParameterValue
- Connection Type
- M20x1.5 Conduit Entry
- Contact Type
- 1NO+1NC
- Maximum AC Voltage
- 500 Vac
- Maximum Current
- 10A
- Maximum DC Voltage
- 600 Vdc
- Mechanical Life
- 100,000 operating cycles
- Mounting Orientation
- Any
- Normal State Configuration
- 1NO+1NC
- Output Type
- Direct opening action
- Pole and Throw Configuration
- SPDT
- Standards Met
- EN ISO 13850, IEC 60947-5-1, IEC 60947-5-5, EN 60947-5-1, EN 60947-1, IEC 60204-1, EN ISO 14119, EN ISO 12100, IEC 60529
ParameterValue
Being a UAE company, our UAE shipments are subject to tariffs. Under DDP (Delivered Duty Paid), all applicable tariffs and fees are calculated and paid upfront at checkout.
Same-day dispatch across UAE
Order before 2 PM (Sun–Thu). Next-day delivery to Dubai, Sharjah, Abu Dhabi. 2–4 days to other emirates.
7-day return window
Sealed, unused items can be returned within 7 days for full refund or replacement.
Compatibility-checked
Our specialists review every bulk quote to ensure the part fits your application before you commit.
