80/55 DBU/M7 Waircom Series BU Double Acting Cylinder | Ø80 mm, 55 mm Stroke, Magnetic Piston, Male threaded

The Waircom 80/55 DBU/M7 is a Series BU compact double-acting pneumatic cylinder featuring a Ø80 mm bore and 55 mm stroke. It is equipped with a magnetic piston, Male threaded, G1/8 pneumatic port, and a M16x1,5 piston rod thread. The cylinder features an Anodized aluminium alloy (20 µm) barrel and a C45 chromium-plated steel piston rod. Compliant with AFNOR NF E49-004-1 / NF E49-004-2, it is suitable for compact automation and positioning applications.
