77.55.8.230.8250 - Finder Solid-State Relay, 50000 mA 280 VAC (Heatsink)

77.55.8.230.8250 - Finder Solid-State Relay, 50000 mA 280 VAC (Heatsink)

AED 194.00
AED 194.00
Sale Sold out
Shipping calculated at checkout.

The 77.55.8.230.8250 is a dependable solid state relay from Finder, part of the 77 series. Rated for a maximum load of 50000 mA at 280 VAC with Zero-Cross switching, controlled by 230 VAC to 230 VAC input. This Heatsink relay uses Zero-Cross output, providing millions of silent, maintenance-free switching cycles for heaters, motors, and process control loads.
View full details

Specifications

  • Brand: Finder
  • Maximum Load Current: 50000 mA
  • Mounting Type: Heatsink
  • Maximum Load Voltage: 280 VAC
  • Minimum Load Voltage: 21.6 VAC
  • Maximum Control Voltage: 230 VAC
  • Switching Type: Zero-Cross
  • Control Voltage Range: 90280 VAC
  • Minimum Load Current: 250 mA
  • Terminal Type: Screw
  • Contact Configuration: SPST
  • Package Style: Hockey Puck
  • Series: 77
  • Load Voltage Range: 21.6–280 VAC
  • Maximum Turn On Time: 40 ms
  • Dimensions: 44.5 x 36.4 x 57.7 mm
  • Depth: 44.5 mm
  • Operating Temperature Range: -30–80 °C
  • Height: 36.4 mm
  • Off State Leakage Current: 10 mA
  • Length: 57.7 mm
