Waircom 63/5500 ZSFF - Series Z Rodless Cylinder with Standard Yoke (63 mm Bore)

Waircom 63/5500 ZSFF - Series Z Rodless Cylinder with Standard Yoke (63 mm Bore)

SKU63/5500 ZSFFBrandWaircom
AED 20,621.00
AED 20,621.00
Sale Sold out
Shipping calculated at checkout.

The Waircom 63/5500 ZSFF is a high-efficiency rodless pneumatic cylinder belonging to the specialized Series Z family. Featuring a space-saving design that offers identical strokes in half the length of conventional cylinders, this unit runs on a 63 mm bore paired with a 5500 mm stroke capacity. Built with a robust standard carriage yoke mechanism, its structurally rigid framework uses an Anodized aluminium alloy (extruded profile) barrel and integrated G 3/8 fluid ports.

View full details
ParameterValue
Brand
Waircom
Series
Series Z
Cylinder Type
Rodless, Standard yoke with Double guide
Yoke Type
Standard
Guide Type
Double guide
Bore Size
63 mm
Stroke
5500 mm
Port Size
G 3/8
Decelerator Length
49 mm
ParameterValue
Magnetic Piston
Yes (as standard)
Barrel Material
Anodized aluminium alloy (extruded profile)
Yoke Material
Anodized aluminium alloy
Sealing Strip
Polyamide
Cover Strip
AISI 304 stainless steel
Seals
Polyurethane
Operating Pressure
2 to 8
Working Temperature
0 to +80 °C (–20 °C with dry air)
