• Waircom - 40/100 DBU/M7
1 1

Waircom 40/100 DBU/M7 - Series BU Double Acting Cylinder (40mm Bore x 100mm Stroke)

Waircom 40/100 DBU/M7 - Series BU Double Acting Cylinder (40mm Bore x 100mm Stroke)

SKU40/100 DBU/M7BrandWaircom
AED 303.00
AED 303.00
Sale Sold out
Shipping calculated at checkout.

The Waircom 40/100 DBU/M7 is a Series BU double acting pneumatic cylinder designed for standard industrial automation. It features a 40mm bore, a 100mm stroke, and a built-in magnetic piston. Constructed with a anodized aluminium alloy (20 µm) barrel and an C45 chromium-plated steel piston rod, it offers strong corrosion resistance. This unit includes a M10x1,25 male threaded rod end and an G1/8 port, fully complying with AFNOR NF E49-004-1 / NF E49-004-2 standards.

View full details
ParameterValue
Brand
Waircom
Series
Series BU
Cylinder Type
Double Acting
Bore Size
40 mm
Stroke
100 mm
Piston Type
Magnetic
ParameterValue
Rod End
Male threaded
Barrel Material
Anodized aluminium alloy (20 µm)
Piston Rod Material
C45 chromium-plated steel
Piston Rod Thread
M10x1,25
Port Size
G1/8
Standards Met
AFNOR NF E49-004-1 / NF E49-004-2
