Waircom 18/90 ZSFF - Series Z Rodless Cylinder with Standard Yoke (18 mm Bore)

Waircom 18/90 ZSFF - Series Z Rodless Cylinder with Standard Yoke (18 mm Bore)

SKU18/90 ZSFFBrandWaircom
AED 2,696.00
AED 2,696.00
Sale Sold out
Shipping calculated at checkout.

In stock

The Waircom 18/90 ZSFF is a high-efficiency rodless pneumatic cylinder belonging to the specialized Series Z family. Featuring a space-saving design that offers identical strokes in half the length of conventional cylinders, this unit runs on a 18 mm bore paired with a 90 mm stroke capacity. Built with a robust standard carriage yoke mechanism, its structurally rigid framework uses an Anodized aluminium alloy (extruded profile) barrel and integrated M5 fluid ports.

View full details
  • Brand: Waircom
  • Series: Series Z
  • Cylinder Type: Rodless, Standard yoke with Double guide
  • Yoke Type: Standard
  • Guide Type: Double guide
  • Bore Size: 18 mm
  • Stroke: 90 mm
  • Port Size: M5
  • Decelerator Length: 15 mm
  • Magnetic Piston: Yes (as standard)
  • Barrel Material: Anodized aluminium alloy (extruded profile)
  • Yoke Material: Anodized aluminium alloy
  • Sealing Strip: Polyamide
  • Cover Strip: AISI 304 stainless steel
  • Seals: Polyurethane
  • Operating Pressure: 2 to 8
  • Working Temperature: 0 to +80 °C (–20 °C with dry air)
