Waircom 160/700 CXL/FM - Series CXL Double Acting, Cushioned Cylinder (160mm Bore x 700mm Stroke)

Waircom 160/700 CXL/FM - Series CXL Double Acting, Cushioned Cylinder (160mm Bore x 700mm Stroke)

SKU160/700 CXL/FMBrandWaircom
AED 3,249.00
AED 3,249.00
Sale Sold out
Shipping calculated at checkout.

The Waircom 160/700 CXL/FM is an industrial double acting, cushioned cylinder belonging to the Series CXL line. Built for demanding automation environments, this pneumatic actuator relies on a 160mm bore and a compact 700mm stroke to deliver reliable linear motion. It features built-in adjustable front + rear decelerators to manage end-of-stroke impact smoothly. Structural construction consists of an anodized aluminium alloy (extruded tube) barrel paired with a c45 chromium-plated steel piston rod. Standard mechanical connections include a G 3/4 port configuration and an M36x2 piston rod thread, fully meeting AFNOR NF E49-001 (ex CNOMO) standard specifications.

View full details
ParameterValue
Brand
Waircom
Series
Series CXL
Cylinder Type
Double Acting, Cushioned
Bore Size
160 mm
Stroke
700 mm
Piston Type
Magnetic
ParameterValue
Cushioning
Adjustable front + rear decelerators
Barrel Material
Anodized aluminium alloy (extruded tube)
Piston Rod Material
C45 chromium-plated steel
Piston Rod Thread
M36x2
Port Size
G 3/4
Standards Met
AFNOR NF E49-001 (ex CNOMO)
