Waircom 100/500 CXL - Series CXL Double Acting, Cushioned Cylinder (100mm Bore x 500mm Stroke)

The Waircom 100/500 CXL is an industrial double acting, cushioned cylinder belonging to the Series CXL line. Built for demanding automation environments, this pneumatic actuator relies on a 100mm bore and a compact 500mm stroke to deliver reliable linear motion. It features built-in adjustable front + rear decelerators to manage end-of-stroke impact smoothly. Structural construction consists of an anodized aluminium alloy (extruded tube) barrel paired with a c45 chromium-plated steel piston rod. Standard mechanical connections include a G 1/2 port configuration and an M27x2 piston rod thread, fully meeting AFNOR NF E49-001 (ex CNOMO) standard specifications.
