IFM IIT213 - Inductive Sensor, M30, Sn 22 mm

IFM IIT213 - Inductive Sensor, M30, Sn 22 mm

SKUIIT213BrandIFM
AED 256.00
AED 256.00
Sale Sold out
Shipping calculated at checkout.

Only 5 left

IFM IIT213 Inductive Sensor — M30 non-flush stainless steel inductive sensor for hygienic areas with extended 22 mm range, PNP NO output and M12 connector. M30, Sn 22 mm, non-flush, PNP NO, 10...30 V DC, 100 Hz, IP 68/IP 69K, stainless steel, M12.

Shipping & Returns

Same-day dispatch across UAE

Order before 2 PM (Sun–Thu). Next-day delivery to Dubai, Sharjah, Abu Dhabi. 2–4 days to other emirates.

7-day return window

Sealed, unused items can be returned within 7 days for full refund or replacement.

Compatibility-checked

Our specialists review every bulk quote to ensure the part fits your application before you commit.

MPN / SKU: IIT213

Also known as: IFM IIT213 proximity sensor / proximity switch.

IIT213 Applications

The IIT213 is an M30 non-flush inductive proximity sensor built for hygienic areas and regular cleaning processes. Its stainless steel housing (316L/1.4404) with a PEEK sensing face resists aggressive detergents and high-pressure washdown while meeting IP 68 / IP 69K. The non-flush design delivers an extended sensing range of 22 mm for reliable non-contact metal detection at greater distances. It provides a PNP normally open output on an A-coded M12 connector with gold-plated contacts, ideal for food, beverage and pharmaceutical equipment.

IIT213 Specifications

Brand IFM Product Type Inductive sensor
IFM Type Code IIK3022-BPKG/V4A/US-104 Sensing range 22 mm
Real sensing range 22 mm ± 10 % Operating distance 0...17.82 mm
Mounting Non-flush mountable Output type PNP
Output function Normally open Operating voltage 10...30 V DC
Current consumption 10 mA Voltage drop 2.5 V
Permanent current rating 100 mA Switching frequency 100 Hz
Housing / thread M30 x 1.5, L = 70 mm Connection M12 connector, A-coded, 3 gold-plated contacts
Protection rating IP 68; IP 69K Ambient temperature 0...100 °C
Housing material Stainless steel (316L/1.4404); sensing face PEEK

IIT213 Datasheet & Manual

Download Datasheet & ManualIFM IIT213 · PDF · Official IFM document

IIT213 – Frequently Asked Questions (FAQ)

What is the sensing range of the IFM IIT213?

The IFM IIT213 has an extended sensing range of 22 mm (22 mm ± 10 %) with an operating distance of 0...17.82 mm.

Is the IFM IIT213 flush or non-flush mountable?

The IFM IIT213 is non-flush mountable, which gives it its extended 22 mm sensing range.

Is the IFM IIT213 suitable for hygienic areas?

Yes, the IFM IIT213 is designed for hygienic areas and regular cleaning with a stainless steel housing and PEEK sensing face.

What output does the IFM IIT213 provide?

The IFM IIT213 provides a PNP normally open output.

What is the operating voltage of the IFM IIT213?

The IFM IIT213 operates on 10...30 V DC with a current consumption of 10 mA.

How is the IFM IIT213 connected?

The IFM IIT213 uses an A-coded M12 connector with gold-plated contacts.

What protection ratings does the IFM IIT213 have?

The IFM IIT213 is rated IP 68 and IP 69K for high-pressure washdown.

What is the switching frequency of the IFM IIT213?

The IFM IIT213 has a switching frequency of 100 Hz.
