IFM IIT210 - Inductive Sensor, M30, Sn 14 mm

Q: What is the sensing range of the IFM IIT210?

The IFM IIT210 has a rated sensing range of 14 mm (14 mm ± 10 %) with an operating distance of 0...11.34 mm.

Q: Is the IFM IIT210 suitable for hygienic areas?

Yes, the IFM IIT210 is designed for hygienic areas and regular cleaning processes with a stainless steel housing and PEEK sensing face.

Q: Is the IFM IIT210 flush mountable?

Yes, the IFM IIT210 is flush mountable in metal.

Q: What output does the IFM IIT210 provide?

The IFM IIT210 has a normally open output with selectable PNP/NPN electrical design.

Q: What is the operating voltage of the IFM IIT210?

The IFM IIT210 operates on 10...36 V DC with current consumption below 10 mA.

Q: What protection ratings does the IFM IIT210 have?

The IFM IIT210 is rated IP 68 and IP 69K for washdown environments.

Q: How is the IFM IIT210 connected?

The IFM IIT210 has a fixed 10 m PVC cable with 3 x 0.34 mm² conductors.

Q: What temperature range does the IFM IIT210 support?

The IFM IIT210 operates from 0 to 100 °C.

SKUIIT210BrandIFM

AED 292.00

Sale Sold out

Shipping calculated at checkout.

Only 5 left

Quantity

IFM IIT210 Inductive Sensor — M30 flush-mountable stainless steel inductive sensor for hygienic areas with PNP/NPN NO output and 10 m cable. M30, Sn 14 mm, flush, PNP/NPN NO, 10...36 V DC, 100 Hz, IP 68/IP 69K, stainless steel, 10 m cable.

Shipping & Returns

Same-day dispatch across UAE

Order before 2 PM (Sun–Thu). Next-day delivery to Dubai, Sharjah, Abu Dhabi. 2–4 days to other emirates.

7-day return window

Sealed, unused items can be returned within 7 days for full refund or replacement.

Compatibility-checked

Our specialists review every bulk quote to ensure the part fits your application before you commit.

MPN / SKU: IIT210

Also known as: IFM IIT210 proximity sensor / proximity switch.

IIT210 Applications

The IIT210 is an M30 flush-mountable inductive proximity sensor designed for hygienic areas and regular cleaning processes. Its fully stainless steel housing (316L/1.4404) with a PEEK sensing face withstands aggressive cleaning agents, high-pressure washdown and IP 68 / IP 69K conditions. It detects metal targets up to 14 mm without contact and provides a normally open output with selectable PNP/NPN operation. A wide 10...36 V DC supply, low current consumption and a fixed 10 m cable make it suited to food, beverage and pharmaceutical machinery.

IIT210 Specifications

Brand	IFM	Product Type	Inductive sensor
IFM Type Code	IIKC014BASKG/M/V4A/10M	Sensing range	14 mm
Real sensing range	14 mm ± 10 %	Operating distance	0...11.34 mm
Mounting	Flush mountable	Output type	PNP/NPN
Output function	Normally open	Operating voltage	10...36 V DC
Current consumption	< 10 mA	Voltage drop	2.5 V
Permanent current rating	100 mA	Switching frequency	100 Hz
Housing / thread	M30 x 1.5, L = 81 mm	Connection	Cable, 10 m, PVC, 3 x 0.34 mm²
Protection rating	IP 68; IP 69K	Ambient temperature	0...100 °C
Housing material	Stainless steel (316L/1.4404); sensing face PEEK
