6059178 - Sick Sensor & Actuator Cable, 5m M8 to Unterminated (3-Core)

6059178 - Sick Sensor & Actuator Cable, 5m M8 to Unterminated (3-Core)

SKU6059178BrandSick
AED 75.00
AED 75.00
Sale Sold out
Shipping calculated at checkout.

The 6059178 is a professional-grade sensor and actuator cable from Sick, part of the M8 series. Measuring 5m in length with 3 cores and 0.25 mm² cross-sectional area, this cable features a M8 Female (Female) connector to Unterminated. Constructed with a Grey Polyvinyl Chloride PVC sheath and rated IP69K, supporting 60 V at 4 A, it is designed for dependable sensor-to-actuator connectivity in industrial automation, robotics, and process control environments.

View full details
ParameterValue
Brand
Sick
American Wire Gauge
24 AWG
Cable Shape
Multicore
Connector 1
M8
Connector 1 Gender
Female
Connector 1 Housing Gender
Female
Connector 1 Number of Contacts
3
Connector 2
Unterminated
Cross Sectional Area
0.25 mm²
Current Rating
4000 mA
IP Rating
IP69K
ParameterValue
Insulation material
PVC
Length
5m
Maximum Operating Temperature
80 °C
Minimum Bend Radius
45 mm
Minimum Operating Temperature
-5 °C
Number of Cores
3
Outer Diameter
4.5 mm
Sheath Colour
Grey
Sheath Material
Polyvinyl Chloride PVC
Shielded/Unshielded
Unshielded
Voltage Rating
60 V
