Waircom EZF3/20PM/SS - EZF G 3/8 Air Filter (20 µm Fine Filtration)

Waircom EZF3/20PM/SS - EZF G 3/8 Air Filter (20 µm Fine Filtration)

SKUEZF3/20PM/SSBrandWaircom
AED 170.00
AED 170.00
Sale Sold out
Shipping calculated at checkout.

The Waircom EZF3/20PM/SS is a high-performance inline pneumatic moisture and particulate filter from the clean air EZF range. Built inside a robust, corrosion-resistant cast aluminium alloy body with standard G 3/8 fluid line connections, it is engineered to house a fine 20 µm filtration element that separates water droplets and micro-contaminants. The unit comes standard with a clear, pm (metallic protection) inspection bowl for simple visual monitoring and features an accessible semi-automatic drainage valve.

View full details
ParameterValue
Brand
Waircom
Series
EZF
Port Size
G 3/8
Filtration
20 µm
Bowl Type
PM (Metallic protection)
Bowl Material
Glass stiffened polyamide (transparent bowl protection, on request)
ParameterValue
Condensate Drainage
Semi-automatic
Body Material
Aluminium alloy
Filtering Element
Sintered polyethylene
Max Pressure
16 bar
Working Temperature
0 ÷ +50 (–10 with dry air)
Max Condensate
23 cm³
