Finder Electromechanical Interface Relays 39.11.8.230.0060

Finder Electromechanical Interface Relays 39.11.8.230.0060

Regular price AED 83.36
Regular price Sale price AED 83.36
Sale Sold out
Shipping calculated at checkout.

Finder, DIN Rail Mount Interface Relay, 240V ac Coil, SPDT

View full details

Specifications

  • Brand: Finder
  • Coil Voltage: 240V ac
  • Contact Configuration: SPDT
  • Mounting Type: DIN Rail
  • Number of Poles: 1
  • Series: 39 Series
  • Load Current Rating: 6A
  • Maximum Input Voltage: 264V
  • Minimum Input Voltage: 20.4V
  • Load Voltage Rating: 250V ac
  • Terminal Type: Screw
  • Switching Voltage: 250 ? 400V ac
  • Depth: 90.7mm
  • Height: 87mm
  • Length: 6.2mm
  • Contact Material: Silver Alloy
  • Input Current: 19mA
  • Input Voltage Range: 20.4 ? 264V
  • Turn On Time: 5ms
  • Life: 60000 cycles
  • Operating Temperature Range: -40 ? +70°C
  • Turn Off Time: 6ms
  • Dimensions: 6.2 x 90.7 x 87mm
  • Minimum Operating Temperature: -40°C
  • Maximum Operating Temperature: +70°C
  • Country of Origin: Italy
