1084020 DFS20A - Incremental Motion Control Sensor, Solid shaft, Square flange (8,192)

Name: 1084020 DFS20A - Incremental Motion Control Sensor, Solid shaft, Square flange (8,192)
Brand: SICK
SKU: 1084020
Price: 2505.00 AED
Availability: InStock

SKU1084020BrandSICK

AED 2,505.00

Sale Sold out

Shipping calculated at checkout.

Available

Quantity

The 1084020 DFS20A is a high-precision motion control sensor engineered for accurate positional tracking and speed monitoring in automated systems. Featuring an incremental interface, this sensor delivers an exact 8,192 resolution and provides a reliable htl / push pull output signal type. Designed for secure and straightforward installation via a solid shaft, square flange and operating on a standard 8 ... 30 v supply voltage, it ensures continuous, fail-safe motion feedback for your industrial machinery.

View full details

Brand: Sick
Series: DFS20A
Pulses Per Revolution: 8,192
Output Signal Type: HTL / Push-Pull
Shaft Diameter: 3/8", With flat
Supply Voltage: 8 ... 30 V
IP Rating: IP65

Interface: Incremental
Minimum Operating Temperature: -30 °C
Maximum Operating Temperature: +85 °C
Mounting Type: Solid Shaft, Square Flange
Connection Type: Male connector, M12, 8-pin, radial, Customer-specific pin assignment
Current Rating: 30 mA
Switching Frequency: 820 kHz
